Ceramic Resonators (CERALOCK)Data Sheet of Base Metal Electrode CERALOCK/Comparison drawings against previous products

This is a comparison table between Base Metal Electrode CERALOCK and previous products.
Only part numbers of typical frequencies are listed.
For another part number, please check the each product detail pages.

Click a part number to browse detailed specifications, packaging data, and other information.
You can request free samples from the website or search for stock of specific part numbers at Murata authorized agents, distributors or trading companies.

Apllicatins	Frequency (MHz)	Tolerance Type*	Previous Product	Base Metal Electrode CERALOCK		Comparison
Apllicatins	Frequency (MHz)	Tolerance Type*	Product Number	Product Number	Data Sheet	Comparison
Automotive	4.000	Tight	CSTCR4M00G15C99-R0	CSTNR4M00GH5C000R0
	8.000	Standard	CSTCE8M00G55A-R0	CSTNE8M00G55A000R0
		Standard	CSTCE8M00G52A-R0	CSTNE8M00G52A000R0
		Tight	CSTCE8M00G15C99-R0	CSTNE8M00GH5C000R0
	10.000	Standard	CSTCE10M0G55A-R0	CSTNE10M0G55A000R0
		Standard	CSTCE10M0G52A-R0	CSTNE10M0G52A000R0
		Tight	CSTCE10M0G15C99-R0	CSTNE10M0GH5C000R0
	12.000	Standard	CSTCE12M0G55A-R0	CSTNE12M0G55A000R0
		Standard	CSTCE12M0G52A-R0	CSTNE12M0G52A000R0
		Tight	CSTCE12M0G15C99-R0	CSTNE12M0GH5C000R0
	16.000	Standard	CSTCE16M0V53C-R0	CSTNE16M0V53C000R0
		Standard	CSTCE16M0V51A-R0	CSTNE16M0V51C000R0
		Tight	CSTCE16M0V13C99-R0	CSTNE16M0VH3C000R0
	20.000	Standard	CSTCE20M0V53C-R0	CSTNE20M0V53C000R0
		Standard	CSTCE20M0V51A-R0	CSTNE20M0V51C000R0
		Tight	CSTCE20M0V13C99-R0	CSTNE20M0VH3C000R0
Consumer and Industrial	4.000	Tight	CSTCR4M00G15L99-R0	CSTNR4M00GH5L000R0
	8.000	Standard	CSTCE8M00G55Z-R0	CSTNE8M00G55Z000R0
			CSTCE8M00G55-R0	CSTNE8M00G550000R0
			CSTCE8M00G52Z-R0	CSTNE8M00G52Z000R0
			CSTCE8M00G52-R0	CSTNE8M00G520000R0
		Tight	CSTCE8M00G15L99-R0	CSTNE8M00GH5L000R0
	10.000	Standard	CSTCE10M0G55Z-R0	CSTNE10M0G55Z000R0
			CSTCE10M0G55-R0	CSTNE10M0G550000R0
			CSTCE10M0G52Z-R0	CSTNE10M0G52Z000R0
			CSTCE10M0G52-R0	CSTNE10M0G520000R0
		Tight	CSTCE10M0G15L99-R0	CSTNE10M0GH5L000R0
	12.000	Standard	CSTCE12M0G55Z-R0	CSTNE12M0G55Z000R0
			CSTCE12M0G55-R0	CSTNE12M0G550000R0
			CSTCE12M0G52Z-R0	CSTNE12M0G52Z000R0
			CSTCE12M0G52-R0	CSTNE12M0G520000R0
		Tight	CSTCE12M0G15L99-R0	CSTNE12M0GH5L000R0
	16.000	Standard	CSTCE16M0V53Z-R0	CSTNE16M0V53Z000R0
			CSTCE16M0V53-R0	CSTNE16M0V530000R0
			CSTCE16M0V51Z-R0	CSTNE16M0V51Z000R0
			CSTCE16M0V51-R0	CSTNE16M0V510000R0
		Tight	CSTCE16M0V13L99-R0	CSTNE16M0VH3L000R0
	20.000	Standard	CSTCE20M0V53Z-R0	CSTNE20M0V53Z000R0
			CSTCE20M0V53-R0	CSTNE20M0V530000R0
			CSTCE20M0V51Z-R0	CSTNE20M0V51Z000R0
			CSTCE20M0V51-R0	CSTNE20M0V510000R0
		Tight	CSTCE20M0V13L99-R0	CSTNE20M0VH3L000R0

* Standard tolerance: Product with ±0.5% initial tolerance.
Tight frequency tolerance: Product with an initial tolerance tighter than the standard tolerance.
