Type 1DX-SPI is a small and high performance module based on Infineon CYW4343W combo chipset which supports Wi-Fi® 802.11b/g/n + Bluetooth® 5.1 BR/EDR/LE up to 65Mbps PHY data rate on Wi-fi® and 3Mbps PHY data rate on Bluetooth®. Interfacing to the Type 1DX-SPI via SPI interface (Wi-Fi®) has been verified by STMicroelectronics. Hardware and software design examples are available based on their highly portable STM32Cube ecosystem, which supports over 1600 devices in full production. (Bluetooth® support is under planning)
The CYW4343W implements highly sophisticated enhanced collaborative coexistence hardware mechanisms and algorithms, which ensure that WLAN and Bluetooth® collaboration is optimized for maximum performance.
Type 1DX-SPI module is packaged in an impressively small shielded form factor that facilitates integration into size- and power-sensitive applications such as IoT applications, handheld wireless system, gateway and more.
