EMI Suppression Filters (EMC and Noise Suppression)Noise Suppression Product PLT10H (Common Mode Choke Coil)
Recommend CASE 3

CASE3 Need to reduce mounting space (downsize)?

I want to reduce the size of the board slightly.

I have been looking for noise suppression products to be used around a power supply; however, all the components I found were too big.

I want to reduce noise satisfactorily while reducing the mounting space to downsize an electronic device.

Murata's PLT10H reduces mounting space!

How?

Can be mounted in a space L 12 mm x W 3 mm*
Compared with common mode choke coils of other companies, about 1/2 the space is required.
Since this is a hybrid type that reduces both common mode noise and differential mode noise (normal mode noise), it can also replace the coil.

*World's smallest mounting space, with the same current as a common mode choke coil.
