Variable Capacitors

Variable capacitors have capacitance values that can be varied by applying voltage to their electrodes.

Product Lineup

▼See the series lineup and specifications here.

What is a variable capacitor (VAC)?

VACs are passive components with capacitance values that can be varied according to the control voltage. They can be considered for applications such as frequency adjustment.

Murata offers products suited to the HF band (13.56 MHz) used for near field communication (NFC)

Characteristics

  1. Compact, slim package
  2. Capacitance variable range of 50%
  3. The capacitance can be finely adjusted by applying voltage.

Basic

  • The variable capacitor absorbs the antenna L value variance for easier f0 adjustment!
  • Easier debugging during certification tests.
  • Easier variance adjustment when building into cases.

Video

Regarding Change the Capacitance

To change the capacitance, apply for DC voltage to V_tune terminal.
It does not change even if AC voltage is applied.

Regarding Connection

Single-end

Differential

You can use the single-end connection as described above.
The same characteristics as differential connection are obtained.
