AMR Simulation Tool

Simplified display of on/off areas in Excel

A simulation tool in Excel format is available that lets you answer the question “What area does the AMR sensor turn on with this magnet?” by just inputting/selecting the information for the specific magnet and sensor.
The tool then displays the area on a simplified on-area map. This is useful when considering where to deploy AMR sensors.

Download AMR Simulation Tool (with manual)

Updated 4/30/2020

Murata Icon XExplanation of how to use the AMR sensor simulation tool

This video compares how the sensor turns on and off when a magnet actually approaches the sensor for each of the cases of opening/closing, sliding, and rotation, and how the magnet enters the detection area on the simulation tool.

Murata Icon XSimulation tool features

Just input information on the magnet material, size, and distance to the sensor and the simulation tool displays the on/off of areas surrounding the AMR sensor position.



Free download

The simulation tool Excel file and manual in PDF format are provided as a compressed file that you can download and use. This allows you to use the simulation tool off-line.

Manual provided

In addition to instructions on using the tool, such as how to read the map and adjust what is displayed, a large number of example applications are provided.

Wide range of settings are available.

You can enter settings such as the size, direction, magnetic characteristics of the magnet, and the PCB orientation for a variety of applications.

Plane settings

You can turn on or off the display of specific planes: XY-plane (top), YZ-plane (side), and XZ-plane (front).

Murata Icon XNumeric value input and selection locations

The simulation tool allows you to input your own settings for the following items.
Note: Refer to the manual for detailed instructions on entering settings.



Murata Icon XArea map display example

As an example, the simulation shows which locations will be in the off state when the AMR sensor is moved in the X and Y directions, respectively, from a samarium-cobalt magnet measuring 3 × 1 × 5 mm, with initial position Pa (Xn = 0, Yn = 0, Zn = 3 mm).



Simulation example 1: Movement of the AMR sensor in the X direction

When the AMR sensor is moved from initial position Pa to Pb, the change is shown below, and a map, such as that shown in the figure is generated.
・Pa(0,0,3)⇒Pb(11,0,3)

The off state is predicted when the AMR sensor’s Xn is approximately 7 to 11 mm.



Distance from magnet center P0 [mm]
Xn Yn Zn
0 0 3
Distance from magnet center P0 [mm]
Xn Yn Zn
11 0 3

Simulation example 2: Movement of the AMR sensor in the Y direction

When the AMR sensor is moved from initial position Pa to Pc, the change is shown below, and a map, such as that shown in the figure is generated.
・Pa(0,0,3)⇒Pc(0,11,3)

The off state is predicted when the AMR sensor distance is approximately 9 to 14 mm, but the cell color is different near Yn = 4 mm.



Distance from magnet center P0 [mm]
Xn Yn Zn
0 0 3
Distance from magnet center P0 [mm]
Xn Yn Zn
0 11 3

Simulation example 3: Expansion of the AMR sensor trajectory

When the AMR sensor is moved to Pc, as in example 2, and the area near Yn = 4 mm is expanded, the change is shown below, and a map, such as that shown in the figure is generated.
・Pa(0,0,3)⇒Pc(0,4,3)
・Y and Z direction display scale factors each set to ×5.0

It is predicted that there will be temporary off states in the area near Yn = approx. 3 to 4 mm.



Distance from magnet center P0 [mm] Display scale factor
Xn Yn Zn X Y Z
0 4 3 ×1.0 ×1.0 ×1.0
Distance from magnet center P0 [mm] Display scale factor
Xn Yn Zn X Y Z
0 4 3 ×1.0 ×5.0 ×5.0

Murata Icon XFrequently asked questions

Q. Are there examples of cases that have been used in actual applications?
Yes, there are. The provided manual includes the following application examples. (The cases shown are examples. They can be applied to other products so long as the magnet and AMR positional relationships are the same.)

  • Open/Close detection (door, lid, etc.)

    Open/Close detection for white goods such as refrigerators, door detection in security applications, notebook PC covers, etc.
  • Slide movement detection 1 (windows and drawers)

    Detection in cases where magnets move in parallel, such as anti-theft applications for windows or sliding doors; position detection of water level in freezer and vegetable compartments of refrigerators, humidifiers, tanks of various types; and so on.
  • Slide movement detection 2 (compact switches and microswitches)

    Detection in cases where on/off operation with a motion length of a few millimeters is desired, such as compact switches on notebook PCs or digital cameras, power switches (which are easily waterproofed) on wearable devices, and compact devices.
  • Position detection for rotating objects

    Auto-lock open-close position sensing, float switch (lever-type) liquid surface detection, detection for cases where on/off should occur at a selected angular width within a particular angle range of a rotating object.
    In addition to various detection examples, pointers on how to make adjustments to achieve a desired on/off angle are provided.
Q. How do you perform actual evaluation?
An evaluation board is available that lets you confirm operation by means of LEDs that turn on and off. First, check the LED on/off status on the evaluation board alone.
Next, use double-sided tape to secure the magnet and evaluation board in place on the equipment on which installation is planned and check the LED on/off status during operation.
This provides a way to study and verify operation before deployment.

AMR (magnetic) sensor evaluation board

Murata Icon XNotes (Make sure to read these carefully.)

* The tool uses a mathematical formula to calculate the magnetic force emanating from the magnet and generates a simplified display of the area in the on state. The calculation is based on a formula derived from the magnet information and user-defined position information (the position of the AMR sensor).


  • The tool cannot calculate the effects of other nearby magnets or parts such as screws or metal plates that affect the magnet.
  • It is important to make sure there are no other magnets or parts that could have an effect nearby. There are no guidelines specifying the minimum necessary, so make sure to confirm operation on the actual device.



* Since there will be some difference between the calculated and actual values, make sure to perform verification on prototypes and the actual product before beginning mass production of the product.


* The manual is subject to changes at irregular intervals due to alterations in the lineup of AMR sensors, addition of application examples, etc. Check regularly to make sure you have the latest version.


* Murata’s AMR sensors are for general commercial applications only. They should not be used for applications such as automotive products where high reliability is essential due to a danger of harm to human life or property should the product fail or malfunction.


* Adequate evaluation should be performed, and multiple failsafe measures implemented, in accordance with the degree of importance or necessity of the function.
