Selection Guide of Timing Devices

A full lineup of MEMS resonator, Ceramic Resonators (CERALOCK) and Crystal Units are now available.

Products Applications Frequency
Frequency Tolerance*
MEMS resonator
Consumer

Reference clock of a small and low-profile devices
(Medical patch type devices, Smart cards, Modules with communication functions, Wearable devices, Wireless earphones)
32.768kHz
±20ppm
Ceramic Resonators (CERALOCK)
Automotive

CAN-BUS
Vehicle ECUs (Safety/Body control, Battery control, Powertrain)

2 to 20MHz
±0.1%
to ±0.5%
Consumer / Industrial

Reference clock applications for microcomputers of various device
(AV, OA, Home appliance and industrial systems)

SMD :
2 to 20MHz
Lead :
3.4 to 70MHz
±0.1%
to ±0.5%
Crystal Units
Automotive

In-vehicle Ethernet/FlexRay
Infotainment

16 to 48MHz
±30ppm
to ±100ppm
Consumer / Industrial

Wireless communication devices
Consumer/Industrial devices

10 to 52MHz
±10ppm
to ±100ppm
