    UWB ModulesType 2HQ

    • under development
    Read more

    Murata Type2HQ is the ultra small UWB module which includes NXP's SR250 UWB chipset, clock, filters and peripheral components.
    Ideally suited for general IoT devices including battery operated devices.

    Features

    Main Features

    • UWB Radar
    • OCPD (On Chip Presence Detection)
    • Chipset : NXP Trimension™ SR250
    • IEEE 802.15.4z HRP PHY compliant
    • UWB Channel 5,9 support
    • Interface : SPI
    • Two-Way ranging and One-Way ranging
    • Angle of Arrival (3D AoA or 2D AoA)
    • Small size : Resin molded + Conformal shielding structure
    • FCC/IC/TELEC Reference Certified (Planning)
    • FiRa compliant

    Product Information

    Item Explanation
    Part Number LBUA0ZZ2HQ
    Grade Consumer
    Frequency UWB Ch 5 & 9
    Frequency MHz (min/max) UWB 6240/8240
    Chipset NXP Trimension™ SR250
    Antenna External
    RF Conn / Antenna Not Included
    Flash 384kB eNV memory for code and data storage allowing fast boot
    Sleep Clock Internal X'tal (32.768kHz)
    System Clock Internal X'tal (38.4MHz)
    Operating Temperature Range −30 to 85
    Mounting Type SMT
    Package LGA
    Dimension 5.9 × 5.7 × 1.05 (max) mm
    Supply Voltage (Vdc)
    • 1.8V for VDDIO or 1.2V for VDDIO
    • 3.3V for VBAT
    Supply Voltage min
    • 1.62V for VDDIO (1.8V) or 1.14V for VDDIO (1.2V)
    • 2.5V for VBAT
    Supply Voltage max
    • 1.98V for VDDIO (1.8V) or 1.26V for VDDIO (1.2V)
    • 5V for VBAT
    Host Interface SPI
    FCC/ISED/MIC (Japan) Certified Planning
    ETSI report Planning

    Block Diagram

    Block Diagram

    Documents

    If you would like a product catalog or technical data, please check the check box and download it from the download button below.

    Swipe left or right to change screens. View in landscape mode.
    Document Name File type Last Update
    Module Product Brief PDF 09/12/2024
    Download

    Related material of environment

    Planning

    Evaluation Kit

    Item Explanation
    Product P/N LBUA0ZZ2HQ-EVK
    Content

    Murata UWB module Type2HQ evaluation board. Type2HQ and Type2FR (NXP RW612), USB-UART conversion IC are on this EVB.

    Power supplied via USB cable, and from COM port of PC, Type-2HQ can be controlled through Type2FR (NXP RW612).
    Image of LBUA0ZZ2HQ-EVK
    Dimension 90 × 45 × 11.6 (mm)

    Please contact our sales or send your inquiry for the evaluation kit.

    Inquiry

    If you have already purchased a Murata EVK, please refer to the technical documents available on my Murata.
