FORTELION 24V Battery Module

Murata's FORTELION 24V Battery Module is built with olivine-type lithium ion iron phosphate secondary batteries (FORTELION), which are known for their longevity, safety, and fast-charging capability.
Murata's FORTELION 24V Battery Module is capable of monitoring each Battery Module's Voltage, Current, Temperature & Capacity Value through CAN communication.
It is possible to customize voltage and capacity in order to meet the requirements of wide range of applications including Robot, AGV, E-Cart, Forklift, etc.

Separate type

ItemsSpecifications
Model NameLIPY032WWPCSY6(Battery Module)
LIA1020WWPACSY6(BMU)
System configurationBattery Module+BMU
Nominal Voltage / Capacity
(per module)
25.6V / 24Ah / 614Wh
Max Discharge Current50A / 40A / 30A
(5sec / 25sec / cont.)
Max Charge Current24A (1C)
Module Max Configuration2s10p
Battery Communication I/FCAN Bus
(Murata original format)
Dust and Water proofNot supported
Safety regulationIEC62133
CE (EMC, RoHS)
Dimension (module)259(L) x 71(W) x 245(H) (mm)
Weight (module)7.3kg (Module)

All-in-one type

ItemsSpecifications
Model NameLIPY041WWPCSY6
System configurationAll-in-one (BMU function is included)
Nominal Voltage / Capacity
(one module)
25.6V / 21Ah / 537Wh
Max Discharge Current100A / 80A / 60A
(5sec / 25sec / cont.)
Max Charge Current42A (2C)
Module Max Configuration2s10p
Battery Communication I/FCAN Bus, U-art
(Murata original format)
Dust and Water proofIP54 rating
Safety regulationIEC/UL62133, IEC62619
UL2271 (Light EV battery)
CE (EMC, RoHS)
Dimension 195(L) x 132(W) x 180(H) (mm)
Weight 6.5kg

PDF Catalog

FORTELION 24V Battery Module (PDF: 0.4 MB)

UP DATE
1/22/2021

Lithium Batteries UN38.3 Test Summary
