Inductors for audio line noise suppression

Inductors for audio line noise suppression
The LQW_CA Series of inductors for audio line noise suppression were developed as filters that are able to balance noise suppression and audio quality.

Murata Icon X Audio line noise suppression

Murata Icon X Specifications

LQW04CA series

External appearance
Part number
Inductance value
Rated current value

LQW04CA60NK00 60nH
620mA
LQW04CA90NK00
90nH
520mA
LQW04CAR12K00
120nH
510mA
LQW04CAR29K00
290nH
270mA
LQW04CAR45K00
450nH
200mA
LQW04CAR51K00
510nH
200mA

LQW15CA series

External appearance
Part number
Inductance value
Rated current value

LQW15CA22NK00
22nH
1300mA
LQW15CA22NJ00
22nH
1300mA
LQW15CA39NJ00
39nH
1100mA
LQW15CA39NK00
39nH
1100mA
LQW15CA59NJ00
59nH
1000mA
LQW15CA59NK00
59nH
1000mA
LQW15CA83NK00
83nH
970mA
LQW15CA83NJ00
83nH
970mA
LQW15CAR11K00
110nH
900mA
LQW15CAR11J00
110nH
900mA
LQW15CAR14K00
140nH
680mA
LQW15CAR14J00
140nH
680mA
LQW15CAR18J00
180nH
640mA
LQW15CAR18K00
180nH
640mA
LQW15CAR22K00
220nH
540mA
LQW15CAR22J00
220nH
540mA
LQW15CAR27J00
270nH
480mA
LQW15CAR27K00
270nH
480mA
LQW15CAR32K00
320nH
420mA
LQW15CAR32J00
320nH
420mA
LQW15CAR37J00
370nH
360mA
LQW15CAR37K00
370nH
360mA
LQW15CAR39J00
390nH 320mA
LQW15CAR39K00
390nH
320mA
LQW15CAR43J00
430nH
360mA
LQW15CAR43K00
430nH
360mA
LQW15CAR50K00
500nH
270mA
LQW15CAR50J00
500nH
270mA
LQW15CAR56J00
560nH
270mA
LQW15CAR56K00
560nH
270mA
LQW15CAR64K00
640nH
240mA
LQW15CAR64J00
640nH
240mA
LQW15CAR73J00
730nH
200mA
LQW15CAR73K00
730nH
200mA
LQW15CAR80J00
800nH
190mA
LQW15CAR80K00
800nH
190mA
LQW15CA1R0K00
1000nH
180mA
LQW15CA2R0K00
2000nH
130mA

LQW18CA series

External appearance
Part number
Inductance value
Rated current value

LQW18CA32NJ00
32nH
2200mA
LQW18CA56NJ00
56nH
1850mA
LQW18CA85NJ00
85nH
1650mA
LQW18CAR12J00
120nH
1500mA
LQW18CAR16J00
160nH
1300mA
LQW18CAR21J00
210nH
1050mA
LQW18CAR27J00
270nH
900mA
LQW18CAR33J00
330nH
780mA
LQW18CAR40J00
400nH
680mA
LQW18CAR48J00
480nH
580mA
LQW18CAR58J00
580nH
450mA
